PDI - Power Disturbance Indicator



Enclosure All metal box painted in flat black color.
Environment 41° F to 113° F
+5° to +45° C
Dimensions/Weight Display box: 8 x 8 x 4 inches
Power measurement box: 8 x 8 x 4 inches
Weight: 12 lbs.
Warranty One Year

Model: PDI-001
Price usd$1200.00
Instantaneous Indication fo AC Power Problems
Input Voltage Range 60 HZ, ±3HZ
Accuracy (Input Voltage Range) +/-2%
Frequency 60 Hz
Update Rates Displayed RMS voltage updated every second. Power Fault LED's updated every 100 ms
Sampling Input sampled 32 times per 1/2 cycle for sags, voltage loss, and surges. Input waveform continuously monitored for spikes.
Specifications Sag:Input voltage decreases to 80% of nominal input for 1/2 cycle duration
Surge: Voltage increase by 12.5% over nominal input for 1/2 cycle duration
Spike: 850 VAC peak +/- 10% for 1 µs minimum duration
Power loss: Input voltage decreases to 50% of nominal input for 1/2 cycle duration
Selection Switch Phase-to-Neutral
Phase-to-Phase
High Voltage 277-489 VAC
Low Voltage 120-240 VAC
Dual Channel Model
Input Protection Resettable fuse. Critical circuits protected against overvoltage damage.

*Specifications subject to change without notice
