Pioneer Power Conditioners


Model: 6KVA 4.8KW
Base Price US
AC INPUT
Input AC Voltage & Circuit Breaker requirements - standard connection
Model # PPC 6-208 208VAC
50A
$3,690.00
Model # PPC 6-240 240VAC
40A
$3,690.00
Line Cord (optional) 208VAC
6-50P

240VAC
6-50P

Input Voltage Window  +15%, -30% of nominal VAC Input @ full load / +15%, -40% of nominal VAC Input @ 50% load
Frequency 60 HZ
Input THD 5% or less
UNIT
Dimension* HxWxD (in.) 17.5 x 17.5 x 21.5
Weight* lbs. 310

Efficiency

91%
BTU's HR/Kw 1619/.475
Noise Attenuation 120db common mode, 60db transverse (normal) mode
Isolation Output is completely isolated from commercial power with less than 2 pf effective capacitive coupling primary to secondary. Secondary has neutral to ground bond, qualifying as a separately derived power source.
Surge Protection 6000 volts are suppressed to safe levels per ANSI/IEEE C62.41 - 1997 category A & B waveforms
Operating Temperature 0° to 40° C (-4° to 104° F)
Relative Humidity 0 to 95% without condensation
High Altitude Operation Max. altitude 10,000 ft - de-rate 1° C off max operating temp per 1000 ft. above sea level
Agency UL 1778, cUL listed
User Interface Keypad w/LCD display, RS232 serial communications, dial in modem

AC OUTPUT
Output AC Voltage  120 / 208 / 240
Output Receptacles  Optional
Output Waveform Computer grade sine wave output power into resistive load
Regulation  ±1% voltage regulation
Load Compatible  Guaranteed compatible with all loads
Overload  150% surge capability, overload alarm 101% load to 125% load for 10 min. before shutdown. Greater than 125% the system will shutdown in 5 seconds
*Specifications subject to change without notice
